address

 bit number

 bit name

180020H

9

N1TPON

 180028H

 13,12

 N1CHCN1, N1CHCN0

 Character Colors

1800D0H

8

N1W0A

 W0 window area

 9

 N1W0E

 W0 window enable

 10

 N1W1A

 W1 window area

 11

 N1W1E

 W1 window enable

 12

 N1SWA

 SW window area

 13

 N1SWE

 SW window enable

 15

 N1LOG

 Window logic

1800E2H

1

N1SDEN

 1800E4H

 6-4

 N1CAOS2 ~ N1CAOS0

 Color RAM address offset

1800E8H

1

N1LCEN

 1800EAH

 3,2

 N1SPRM1, N1SPRM0

 Special priority mode

1800ECH

1

N1CCEN

 1800EEH

 3,2

 N1SCCM, N1SCCM0

 Special color operation mode

 1800F8H

 10-8

 N1PRIN2 ~ N1PRIN0

 Priority number

 180118H

 12-8

 N1CCRT4 ~ N1CCRT0

 Color calculation ratio

180110H

1

N1COEN

180112H

1

N1COSL
