CDC_ERR_OK

 The function ended normally.

 CDC_ERR_CMDBUSY

 When a command is issued, the command end flag is not 1.
 Target: All functions that check the command end flag

 CDC_ERR_CMDNG

 When the command is issued, the CMOK flag is not 1.
 Target: All functions that issue commands

 CDC_ERR_TMOUT

 Timed out. (Waiting for response and waiting for data transfer)
 Target: All functions that issue commands
 CDC_GetPeriStat function, CDC_DataReady function

 CDC_ERR_PUT

 Waiting sector could not be reserved while waiting for data transfer preparation by writing sector data.
 Target: CDC_DataReady function after executing the CDC_PutSctData function

 CDC_ERR_REJECT

 command is now REJECT.
 Target: All functions that issue commands

 CDC_ERR_WAIT

 The response to the command is WAIT.
 Target: All functions that issue commands

 CDC_ERR_TRNS

 The data transfer size is abnormal.
 Target: Internal data transfer function (function starting with CDC_Tget)

 CDC_ERR_PERI

 Could not get periodic response.
 Target: CDC_GetPeriStat function
