(a) When Adr = 1


Ctrl Adr: CONTROL / ADR byte
TNO: Track number (binary value, not BCD)
X: Index number (binary value, not BCD)
P_FAD: Track time (frame address format with track head set to 0)
Q_FAD: Absolute time (frame address format with 00:00:00 as 0)

The contents in each status are the same as in the CD report.
The following table shows the values ​​for each TNO.
(Lead-in and Lead-out can be acquired in multiple sessions)

TNO	X	P_FAD
01H-63H (1-99)	01H-63H	Track FAD in track
AAH (Leadout)	01H-63H	track In progress FAD
00H (Lead-in)	01H to 63H, A0H, A1H, A2H	000000H

The lead-in for the first session is Q_FAD = 000000H.
(Normally not available)

(b) Other (ADR ≠ 1): The value of subcode Q as it is (10 bytes other than CRC)
