offset | size | data Contents | Description |
+ 00h | 4B | Reserved area | − |
+ 04h | 4B | Waveform editing start address | Start address of waveform editing RAM area |
+ 08h | 4B | Total waveform editing size | Total size of waveform editing RAM area |
+ 0Ch | 2B | Reserved area | − |
+ 0Eh | 4B | Voice editor start address | timing editor RAM area start address |
+ 12h | 4B | Tone Editor total size | Total size of the sound editor RAM area |
+ 16h | 2B | Reserved area | − |
+ 18h | 4B | TrgtMem_DSPprogAddress | DSP linker dedicated area |
+ 1Ch | 4B | TrgtMem_DSPprogSize | DSP linker dedicated area |
+ 20h | 32B | TrgtMem_Filename | DSP linker dedicated area |
+ 40h | 4B | TrgtMem_DSPRAMSize | DSP linker dedicated area |
+ 44h | 2B | TrgtMem_RBL | DSP linker dedicated area |
+ 46h | 4B | TrgtMem_ModElementAddress | DSP linker dedicated area |
+ 4Ah | 4B | TrgtMem_ModElementSize | DSP linker dedicated area |
+ 4Eh | 1B | TrgtMem_NumberOfElements | DSP linker dedicated area |
+ 4Fh | 49B | Reserved area | − |
+ 80h | 4B | Voice 1 monitor | Voice # / Note / Velocity |
| | | | | | |
+ FCh | 4B | Voice 32 monitor | Voice # / Note / Velocity |
