1.3 System image

Figure 1.1 shows the data flow for Saturn Author.


Figure 1.1 Data flow

1.4 Usage environment

The usage environment varies depending on the program.

Table 1.2 Saturn author usage environment
 Program
 Environment
 Author Editor


 Macintosh

 		  CPU: 68040 or higher
 RAM: 32MB or more
 HD: 1GB or more

 Author Converter


 PC / AT or compatible machine

 (virtual CD environment is used) 		  CPU: 80486 or more
 RAM: 8MB or more
 HD: 1GB or more

 Author Player
 Saturn

Data and movie files output by the author editor are moved to the author converter PC. Since movie files are large, it is necessary to connect the Macintosh and PC / AT to a LAN such as EtherNET so that data can be transferred from the Macintosh to the PC / AT. Or you can use large capacity media such as MO.
